尺寸

寬

1,037 mm (40-13/16")

高

131 mm (5-3/16")

深

396 mm (15-9/16")

重量

重量

15 kg (33 lbs., 1 oz.)

鍵盤

琴鍵數

61

種類

FSX Keyboard

先觸感應

Yes

後觸感應

Yes

音色產生器

Motion Control Synthesis Engine AMW2: 8   Elements FM-X: 8 Operators, 88 Algorithms

最大值複音

AWM2: 128 (max.; stereo/mono waveforms)   FM-X: 128 (max.)

多音色容量

16 Parts (internal), Audio Input Parts   (A/D*, USB*) *stereo Part

波形

Preset: 5.67 GB (when converted to 16 bit   linear format), User: 1.75 GB

表演

Approx. 1,900

濾波器

18 types

效果

Reverb x 12 types, Variation x 76 types,   Insertion (A, B) x 76 types*, Master Effect x 15 types *A/D part insertion x   71 types (Preset settings for parameters of each effect type are provided as   templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands)

控制器

Master Volume, AD Input Gain knob, Pitch   Bend wheel, Modulation wheel, Ribbon Controller, Control Sliders x 8, Knobs x   8, Super Knob, Data dial

顯示

7" TFT Color Wide VGA LCD touch   screen

連線器

[USB TO DEVICE], [USB TO HOST], MIDI   [IN]/[OUT]/[THRU], FOOT CONTROLLER [1]/[2], FOOT SWITCH   [ASSIGNABLE]/[SUSTAIN], OUTPUT (BALANCED) [L/MONO]/[R] (6.3 mm, Balanced TRS   jacks), ASSIGNABLE OUTPUT (BALANCED) [L]/[R] (6.3 mm, Balanced TRS jacks),   [PHONES] (6.3 mm, standard stereo phone jack), A/D INPUT [L/MONO]/[R] (6.3   mm, standard phone jacks)

耗電量

27 W

附件

AC Power cord, Owner’s Manual, Cubase AI   Download Information

Live Sets

Preset: 128 and more, User: 2,048

Tracks

16 Sequence tracks, Tempo track, Scene   track

Recording type

Real time replace, Real time overdub,   Real time punch in/out

Note Capacity

Approx. 130,000 notes

Note Resolution

480 ppq (parts per quarter note)

Tempo (BPM)

5 – 300

Songs

64 songs

Arpeggio

Parts: 8 Parts simultaneous (max.),   Preset: Approx. 10,000 types User: 256 types

Sequence formats

MONTAGE original format, SMF formats 0, 1
